重要性传统手工艺技术指标：Main Technical Parameters

设备 Model	CLFQ-QW1300	CLFQ-QW1600
zui大资料屏幕宽度匹配MAX. Width of raw material	1300mm	1600mm
zui大放卷尺寸Max.parent Web Diameter	Φ1500mm	Φ1500mm
zui大收卷内径Max.Rewinding Diameter	Φ1000mm	Φ1000mm
zui高机设备传输速率 Max.Machine Speed	10-400m/min	10-400m/min
总效率 Total Power	25KW	29KW
权重 Machine Weight	4300kg	4800kg
的形状尺寸图 Overall Dimensions	3200×2900×2000mm	3200×3200×2000mm
zui小模切：宽度 Min.Slitting Width	20mm	20mm

可按照产物请求 特别订制装备。

Can be made according to the product requires special equipment.

产物申明

共用产值该设备混用于各项更大一些的sbs防水的模切，如30g/m2-400g/m2头层包装纸、白纸盘、淋膜纸、铝泊、PVC塑胶片、锡纸等sbs防水的模切、复卷等。机器及独特的1. 这手机包容异步伺服电机机械(矢量素材机械)有节制、主動锥度表面张力，中央卷取体例。电脑主机包容定频控速，保持变快中若衡启用。2. 主动性计米、提醒效率。收卷去接纳A、B气胀轴结构，卸装支配便于。3. 放卷容纳光電相互纠偏改进标准体系，使不理论素材能一般来说分割。4. 被动调刀体系建设（輸出你需注意的分切机规格尺寸做次排好加工中心刀具），圆刀纵切废边被动尾气排放标准零件。 5. 液压式活跃长短料，无轴装卷。6.导轨式主動开料装配工艺。

product manual

Scope of applicationThis machine is suitable for the slitting and rewinding of various super large coils, such as 30g/m2-400g/m2 kraft paper, white cardboard, coated paper, aluminum foil, PVC plastic, tin foil and other coils.performance and characteristics1. The machine adopts asynchronous servo motor (vector motor) control, automatic taper tension, and center winding mode. The host adopts frequency conversion speed regulation to maintain a balanced operation during acceleration.2. Automatic meter counting and alarm function. The rewinding adopts A and B inflatable shaft structure, which is easy to unload and operate.3. The unwinding adopts the photoelectric automatic correction system to make the irregular materials can be slit normally.4. Automatic tool adjustment system (input the slitting specifications you need to arrange the tools at one time), and the automatic discharge device for round knife longitudinal cutting waste.5. Hydraulic automatic loading and unloading, without shaft loading.6. Guide rail type automatic unloading device.
