终产物声明函　　配伍范围　　远程服务器共用于四种很较大型板料的分割，如30g/m2-300g/m2牛皮革纸、白硬纸板、淋膜纸、镀铝、PVC泡沫塑料、编织方法袋、锡纸等板料的分割、复卷等。　　器能及苏州特色　　1. 设备使用异步步进驱动器建筑机械(矢量素材建筑机械)控制、自动锥度支撑力，后面卷取体例。监控主机使用定频变频调速，追求减缓中其衡启动。　　2. 主動计米、提醒功用。收卷容纳A、B气胀轴页面布局，卸装支配快捷。　　3. 放卷接纳孩子光电科技自主的纠偏纠错管理体制，使不法則材料能大部分模切。　　4. 圆刀纵切废边主动性废气排放加装。5. 油压机式活跃放料，配气胀轴。6.导轨式自主的开料裝配。也可单向拉开卸料！product manualScope of applicationThis machine is suitable for the slitting of various super-large coils, such as slitting and rewinding of 30g/m2-300g/m2 kraft paper, white cardboard, coated paper, aluminum foil, PVC plastic, Woven bag, tin foil and other coils.Performance and characteristics1. The machine adopts asynchronous servo motor (vector motor) control, automatic taper tension and center winding method. The main engine adopts frequency conversion speed regulation to maintain balanced operation during acceleration.2. Automatic metering and alarm function. The winding adopts the A and B air expansion shaft structure, and the unloading operation is convenient.3. Unwinding adopts photoelectric automatic correction correction system to make irregular materials cut normally.4. The circular knife cuts the waste side automatic discharge device.5. Hydraulic automatic feeding, with air expansion shaft.6. Rail type automatic cutting device. The unloading can also be opened unilaterally! 　　主要一技之长性能参数：Main Technical Parameters

机种 Model	CLFQ-W800	CLFQ-W1300
zui大材料厚度MAX. Width of raw material	800mm	1300mm
zui大放卷孔径Max.parent Web Diameter	Φ1400mm	Φ1400mm
zui大收卷长度Max.Rewinding Diameter	Φ1100mm	Φ1100mm
zui高系统传输速度 Max.Machine Speed	10-400m/min	10-400m/min
总效率 Total Power	22KW	25KW
图像 Machine Weight	4000kg	4800kg
图型规格尺寸 Overall Dimensions	2500×2900×2000mm	3000×2900×2000mm
zui小分切机厚度 Min.Slitting Width	50mm

可确定副产物重定向 尤其是定制大小转备。Can be made according to the product requires special equipment.  缩短来关头词：手编袋内阀膜分割机，阀兜里膜分割机
